Мини-ПК XCY без вентилятора, Intel Core i3 4010U i5 4200U i7 4500U Windows Linux 2x RS232 Dual LAN HDMI VGA 4xUSB3.0 Wi-Fi DDR3L mSATA SSD

Processors

Intel Core i3-4010U, 3M Cache, 2 cores, 4 threads, 1.70GHz

Intel Core i3-5005U, 3M cache, 2 cores, 4 threads, 2.0GHz

Intel Core i5-4200U, 2 cores 4 threads, 3M Cache, 1.60Ghz up to 2.60 GHz

Intel Core i5-5200U, 3M Cache, 2 cores, 4 threads, 2.20GHz, up to 2.70GHz

Intel Core i7-4500U, 4M Cache, 2 cores, 4 threads, 1.80GHz, up to 3.0GHz

Intel Core i7 5500U, 2 core 4 threads, 4M Cache, 2.40GHz up to 3.00 GHz

Memory

1x SODIMM, DDR3L 1333/1600MHz, 1.35V

4010U/4200U/4500U max support to 8GB RAM

5005U/5200U/5500U max support 16GB RAM

Storage

Support 1x mSATA SSD ( defaulted install this type hard drive )

Support 1x 2.5 inch SATA HDD/SSD

Graphics

Intel HD Graphics

Network Interfaces

2x GbE RJ45 Realtek 8111E

Expansion

Mini PCI-E for WiFi/Bluetooth module (half height size )

OS Support

Windows 7/8/10, Linux/Ubuntu

USB Ports

4x USB3.0

Display Port

1x VGA, 1x HDMI

i3-4010U/i5-4200U/i7-4500U: max 3200x2000@60Hz

i3-5005U/i5-5200U/i7-5500U max 2560x1600@60Hz

Serial Ports

2x RS232

Audio Ports

3.5mm combo audio jack 2-in-1

Construction

Fanless passive cooling

Case

Aluminum Case

Dimension

180x125x55mm

Netweight

0.8Kg

Operating

Temperature

-20℃ to +60℃

RH

5%~90% @30℃，Non-condensing

Power Adapter

Input AC100-240V, Ouput DC12V-5A

Package List

1x Mini PC

1x AC Adapter

1x Power cord ( EU AU US UK type plug shipped according to buyer’s address )

1x SATA cable

1x User manual
