Универсальный DC 12V 24V 36V 48V 10A 4CH 30A реле RF беспроводное радио дистанционное управление 433 mhz или 315mhz промышленныйсельскохозяйственный

C. 1-6CH Toggle-- -- Press Transmitter Button “3” to learn

D. 1-3CH Momentary, 4-6CH Toggle------Press Transmitter Button “4” to learn

E. 1-3CH Momentary, 4-6CH Latched------ Press Transmitter Button “5” to learn

F. 1-3CH Latched, 4-6CH Toggle------- Press Transmitter Button “6” to learn

Momentary------------Press the Transmitter button 1, the receiver relay 1th is ON, release button 1; the receiver relay 1th is OFF, the same as 2/3/4/5/6 are independent.

Toggle---------------Press transmitter button 1 for 1 time, the receiver relay 1th is ON, press button 1 again, the receiver relay 1th is OFF, the same 2/3/4/5/6 are independent.

 Latched------------------

Press transmitter button 1, the receiver relay 1th is ON, the relay 2/3/4/5/6 is OFF.

Press transmitter button 2, the receiver relay 2th is ON, the relay 1/3/4/5/6 is OFF.

Press transmitter button 3, the receiver relay 3th is ON, the relay 1/2/4/5/6 is OFF

Press transmitter button 4, the receiver relay 4th is ON, the relay 1/2/3/5/6 is OFF.

 …………….

It also mean .Latched only can keep 1CH ON .and it will often have 1CH is ON.

3. Learning way and steps

1. Press the learning Button of the receiver and buzzer keep tweeting, indicate enter into the status of learning

2. Press the Relative button of the transmitter to learn Relative output way, indicate learning success as the buzzer tweet “Be Be Be” 3 sounds ,and then you press the transmitter Button you can hear the relay act sound. The receiver automatically exits learning state if you do nothing in 32 seconds.

4. Delete memory message (Must clear the code before you learn different button )

Keep pressing the learning Button of the receiver, the buzzer buzzer tweet and “Be Be Be Be  “ (please do not wait for it Be for 6 sounds) then release the button , indicate success to delete the memory message.
